Chronic myeloid leukemia (CML)

Malignant Hematology
Chronic Myeloid Leukemia (CML)

Pathogenesis

Diagram of the t(9;22) translocation forming the Philadelphia chromosome with the BCR::ABL1 fusion, the p190, p210 and p230 transcripts by BCR breakpoint, and boxes on confirming the fusion, Ph-negative CML and CML look-alikes (CSF3R-mutant CNL, LAP score).
t(9;22)(q34;q11) creates BCR::ABL1 on the Philadelphia chromosome; the BCR breakpoint determines the p190, p210 or p230 transcript. Tap to enlarge.
  • Hallmark: myeloproliferative neoplasm of uncontrolled proliferation of mature and maturing granulocytes, defined by the Philadelphia chromosome, t(9;22)(q34;q11), which fuses BCR to ABL1. ABL1 tyrosine kinase catalytic activity becomes unregulated by fusion with BCR, driving uncontrolled granulocytic proliferation.
  • Transcript variants: p210 (e13a2/e14a2, typical CML, including lymphoid blast crisis); p190 (e1a2, most Ph+ ALL with a different breakpoint, rare CML); p230 (e19a2, associated with chronic neutrophilia). ~98% express e13a2/e14a2; atypical transcripts (e1a2, e19a2, e13a3, e14a3) total ~1 to 2%, of which e13a3/e14a3 are a rare subset. CSF3R mutation is seen in chronic neutrophilia (CNL), not CML.
  • Diagnosis of Ph: karyotype, FISH, or PCR for the p210 transcript. FISH is the first diagnostic test to send. BM aspirate + biopsy is mandatory for cytogenetics and phase determination.
  • Ph-negative CML: ~5% lack the Ph chromosome despite the BCR-ABL1 rearrangement (cryptic insertion, or sequential translocations reconstituting normal chromosome morphology). If a presumed-CML patient is Ph-negative, evaluate for BCR-ABL1 expression: these patients may respond to TKIs.
  • Epidemiology: median age ~65, ~9,000/yr US, ~15% of all leukemias. TKIs made CML a chronic disease with life expectancy approaching normal, so prevalence is rising.

Presentation & Diagnosis

  • Symptoms: often asymptomatic (incidental WBC); fatigue, weight loss, night sweats, abdominal fullness from splenomegaly.
  • Blood smear: leukocytosis with the full spectrum of the neutrophilic series, predominance of neutrophils and myelocytes ("myelocyte bulge"), basophilia and eosinophilia, thrombocytosis; NO dysplasia. LAP score is LOW (vs reactive leukocytosis, which has high LAP).
  • Bone marrow: hypercellular, granulocytic hyperplasia, elevated M:E ratio, small hypolobated ("dwarf") megakaryocytes; reticulin may be present.
  • Pre-treatment evaluation: BCR::ABL1 transcript on the International Scale (IS); kinase-domain (KD) mutation screen if AP/BP or TKI failure.

CML phases

CML phases
PhaseDefinition
Chronic phase (CP)~85% of patients at diagnosis; ~1% progress annually on TKI therapy (untreated CP historically progressed to BP in a median of 3 to 5 years).
Accelerated phase (AP)
  • 10 to 19% blasts in blood or marrow
  • ≥20% basophils in blood
  • (historical WHO 2016/MDACC AP criteria) Persistent platelets <100K unrelated to therapy or >1 million unresponsive to therapy. Current ICC 2022 AP = 10 to 19% blasts, basophils ≥20%, or new clonal cytogenetic abnormalities in Ph+ cells; WHO 5th edition eliminates AP.
  • Increasing splenomegaly or WBC on therapy
  • Marked myelofibrosis
  • Additional/​clonal cytogenetic abnormalities with lack of response
Blast phase (BP)
  • ≥20% blasts in marrow or blood; large clusters of blasts on biopsy; can have extramedullary presentation
  • Myeloid ~70%, lymphoid ~30%
Any increase in lymphoblasts is concerning for BP.
  • WHO 2022 reclassified CML as a biphasic disease, eliminating AP as a distinct entity (high-risk features are now "CP with high-risk features" or BP); ICC 2022 retains AP; ELN 2025 acknowledges the controversy and does not fully endorse either classification.
  • "Major route" additional cytogenetic abnormalities (ACAs): second Ph chromosome, trisomy 8, trisomy 19, isochromosome 17q (loss of 17p/TP53). Minor route = all others. Major-route ACAs associate with longer time to CCyR, lower MMR, shorter PFS and OS.
  • Poor-prognosis baseline cytogenetics: i(17)(q10), -7/del(7q), 3q26.2 rearrangements.

Risk scoring at diagnosis

CML risk scoresSokal, Hasford, EUTOS, ELTS
ScoreVariablesNote
SokalAge, spleen, platelets, blastsOriginal score; predicts response to imatinib.
Hasford (Euro)Age, spleen, platelets, blasts + basophils + eosinophilsAdds basophils and eosinophils.
EUTOSBasophils, spleenPredicts response to imatinib.
ELTSAge, spleen, platelets, blastsPreferred in the TKI era; similar to Sokal for low-risk but better in high-risk patients.
ELTS = EUTOS Long-Term Survival.
  • Use: high-risk Sokal/ELTS favors a second-generation TKI or asciminib first-line; low-risk makes imatinib reasonable. Older age favors imatinib.

Response definitions

Log-scale chart of BCR::ABL1 (IS) against months on TKI showing ELN optimal milestones of 10% at 3 months, 1% at 6 months and 0.1% (MMR) at 12 months, the deeper MR4, MR4.5 and MR5 levels, the TFR zone, and boxes on near-miss at 3 months, failure, and TFR criteria.
Molecular response levels on the International Scale with ELN optimal milestones and the MR4 threshold used for treatment-free remission. Tap to enlarge.
CML response definitionsHematologic, cytogenetic, molecular
LevelResponseDefinition
HematologicCHRComplete hematologic response: Normal differential, WBC <10, platelets <450, no palpable splenomegaly, no circulating immature cells, <5% basophils.
CytogeneticMCyRMajor cytogenetic response: 0 to 35% Ph+ marrow metaphases.
CCyRComplete cytogenetic response: 0% Ph+ marrow metaphases; target by 12 months.
MolecularMMR (MR3)BCR-ABL1/ABL ≤0.1% IS; target by 12 months (ELN optimal).
MR4BCR-ABL1 ≤0.01% IS.
MR4.5BCR-ABL1 ≤0.0032% IS (4.5-log reduction).
MR5BCR-ABL1 ≤0.001% IS.
  • Milestones (ELN): 3 months optimal ≤10%; 6 months optimal ≤1%; 12 months optimal ≤0.1% (MMR); warning and failure thresholds escalate accordingly. Early molecular response (EMR, ≤10% by 3 to 6 months) is associated with good outcomes.
  • Key concept: losing CCyR represents more substantial resistance than isolated loss of MMR, but mutation status cannot be inferred from either event; send kinase-domain mutation testing when resistance is suspected. CCyR at 12 mo and PCyR at 3 mo correlate with survival; MMR correlates with EFS. BM biopsy/cytogenetics at diagnosis; thereafter monitor response by peripheral-blood BCR::ABL1 qPCR (IS), repeating marrow only for failure to reach milestones, suspected progression, or unexplained cytopenias.
  • ELN 2025 nuance: switching on failure is no longer automatic; individualize for comorbidity, transcript dynamics, prior toxicity. Prefer dose reduction to manage AEs over switching when efficacy is preserved. On failure, send BCR::ABL1 KD mutation analysis and check adherence and drug interactions first.
  • Per NCCN, a patient with >50% reduction from baseline or a value minimally above the 10% cutoff can continue the same dose of dasatinib/nilotinib/bosutinib for another 3 months; imatinib should NOT be continued at the same 400 mg dose in that scenario (rationale for dose escalation).

TKI Therapy: first-line CP CML

CML First-line TKIs (FDA-approved options + dosing)
  • Imatinib (Gleevec, 2001): 400 mg PO QD with food. First-gen ATP-competitive. Cheap (generic). Suitable for low-risk Sokal/ELTS. AEs: edema, GI upset, myelosuppression, muscle cramps, rash. IRIS 10-yr OS ~83.3% (68.6% high Sokal, 89.9% low Sokal; Hochhaus NEJM 2017). IRIS (O'Brien NEJM 2003): imatinib vs IFN-alfa + cytarabine; MCyR 87.1% vs 34.7%, CCyR 76.2% vs 14.5%, freedom from progression 96.7% vs 91.5%.
  • Dasatinib (Sprycel, 2010 first-line): 100 mg PO QD CP, 140 mg AP/BP. Second-gen, broad-spectrum (also SRC), binds active and inactive ABL conformations. Crosses the BBB (best TKI option for CNS disease). DASISION (Kantarjian NEJM 2010): faster/deeper responses vs imatinib (12-mo confirmed CCyR 77% vs 66% (CCyR on any assessment 83% vs 72%); 5-yr cumulative MMR 76% vs 64%) but no OS/PFS difference at 5 yr (5-yr OS 91% vs 90%). AEs: pleural effusion (~20 to 28% over time; more common age >65), pulmonary HTN (rare, reversible), myelosuppression, bleeding (platelet dysfunction), QTc.
  • Nilotinib (Tasigna, 2010 first-line): 300 mg PO BID newly dx, 400 mg PO BID second line. Empty stomach (no food 2 hr before / 1 hr after: bioavailability + QTc). ENESTnd (Saglio NEJM 2010): deeper MMR/MR4.5 vs imatinib (10-yr MMR ~78% vs 62.5%; 10-yr MR4.5 61% vs 39.2%) with no OS difference; 10-yr cumulative cardiovascular events 16.5 to 23.5% (nilotinib) vs 3.6% (imatinib). AEs: cardiovascular events (PAOD, MI, CVA; warning, not boxed), QTc prolongation (black-box; hold if QTc >480), hyperglycemia, hypercholesterolemia, hyperbilirubinemia (Gilbert/UGT1A1), pancreatitis. Nilotinib is dosed BID; asciminib is also BID in some regimens (40 mg BID option, 200 mg BID for T315I).
  • Bosutinib (Bosulif, 2017 first-line): 400 mg PO QD newly dx, 500 mg QD second-line and beyond. Dual SRC/ABL inhibitor. BFORE (Cortes JCO 2017): 12-mo MMR 47.2% vs 36.9%, 12-mo CCyR 77.2% vs 66.4% vs imatinib. AEs: diarrhea (~10.8% grade ≥3, early, subsides), transaminitis, myelosuppression; less cardiovascular signal than nilotinib. Approved for CP CML resistant/intolerant to prior therapy; usable in third or later lines (esp. for intolerance with a suitable mutation profile). Asciminib or ponatinib generally preferred for true resistance after multiple TKIs.
  • Asciminib (Scemblix): mechanistically distinct STAMP (Specifically Targeting the ABL Myristoyl Pocket) inhibitor: allosteric, binds the vacant myristoyl pocket normally occupied by the myristoylated N-terminus of ABL1, NOT ATP-competitive; high selectivity for ABL1 with activity against ATP-site mutants including T315I. FDA Oct 2021 for CP CML after ≥2 prior TKIs (80 mg QD or 40 mg BID) and for T315I (200 mg BID). Oct 29, 2024 accelerated approval first-line for newly dx CP CML at 80 mg PO QD based on ASC4FIRST (Hochhaus NEJM 2024): week 48 MMR 68% asciminib vs 49% IS-TKIs (P=.001), vs imatinib 69% vs 40%. Favorable AE profile (grade ≥3 AEs 38% asciminib vs 44% imatinib vs 55% 2G-TKIs). Class AEs: thrombocytopenia, pancreatic enzyme elevation, hypertension, rare cardiovascular events. Consider for cardiovascular comorbidities.
Second-generation TKI vs imatinib (12-month efficacy)
Second-generation TKI vs imatinib12-month efficacy, %
2G TKICCyR vs imatinib (%)MMR vs imatinib (%)Transformation vs imatinib (%)
Nilotinib 300 mg BID80 vs 6544 vs 221 vs 4
Dasatinib 100 mg daily83 vs 7246 vs 281.9 vs 3.5
Bosutinib 400 mg daily77 vs 6647 vs 371.6 vs 2.5

Later-line and T315I-active TKIs

Schematic of the BCR::ABL1 kinase showing ATP-competitive TKIs (imatinib, dasatinib, nilotinib, bosutinib, ponatinib) at the ATP site with the T315I gatekeeper, asciminib at the allosteric myristoyl pocket, and omacetaxine acting on the ribosome, with T315I treatment options.
Binding sites of CML drugs: ATP-site TKIs, the allosteric STAMP inhibitor asciminib, and omacetaxine at the ribosome. Tap to enlarge.
  • Ponatinib (Iclusig): third-gen, active against T315I. PACE (phase 2): among CP CML, MCyR 56% overall including 70% of T315I patients; AP CML major hematologic response 55%; BP CML major hematologic response 31%. Only TKI (besides asciminib 200 mg BID) effective against T315I. High rate of vascular events (MI, CVA, PAD); collaborate with cardiology to optimize risk factors. OPTIC (Cortes Blood 2021): response-adapted dosing, start 45 mg then reduce to 15 mg QD on achieving ≤1% IS, reduces arterial occlusive events while preserving efficacy; FDA label updated Dec 2020.
  • Vodobatinib: third-gen TKI investigated for patients who progressed on 4 TKIs.
  • Omacetaxine mepesuccinate (formerly homoharringtonine): a protein synthesis inhibitor that does NOT bind BCR-ABL; binds the A-site cleft of the large ribosomal subunit, blocking chain elongation. FDA-approved for CP or AP CML with resistance/intolerance to ≥2 TKIs; a historical treatment option at progression, not upfront (Synribo is commercially discontinued in the US).

Resistance & BCR-ABL1 kinase-domain mutations

BCR::ABL1 mutation-to-TKI guide (CRITICAL, must memorize)
BCR-ABL1 mutation-directed TKI selectionMust memorize
Mutation / TKISelection
T315IGatekeeperPonatinib, asciminib (200 mg BID), omacetaxine, allogeneic transplant. Pan-resistant to imatinib, dasatinib, nilotinib, bosutinib.
NilotinibUse for V299L, T315A, F317L/V/I/C
DasatinibUse for Y253H, E255K/V, F359V/C/I
BosutinibUse for F317V/I/C, F359V/C/I, T315A, Y253H. E255K/V are poorly sensitive to bosutinib (limited data); prefer dasatinib, ponatinib, or asciminib.
  • Resistance patterns: bosutinib fails with T315I, V299L, G250E, or F317L (retains activity against F317V/I/C). Dasatinib fails with T315I/A, F317L/V/I/C, or V299L. Nilotinib fails with T315I, Y253H, E255K/V, or F359V/C/I.
  • Asciminib resistance: myristoyl-pocket mutations (e.g. A337V, P465S); it maintains activity against most ATP-pocket mutations including T315I.
  • Compound mutations (two mutations on the same allele) are particularly resistant.

Treatment-Free Remission (TFR) / discontinuation

  • Overall success: about 50% of selected patients maintain response after stopping.
  • Key trials: STIM (imatinib): ~41% maintained CMR after stopping; many who relapsed regained CMR on rechallenge. EURO-SKI: sustained MR4.0 for ≥3 years was the strongest predictor of successful discontinuation; molecular relapse-free survival ~61% at 6 months and ~50% at 24 months (so ~39% lost MMR by 6 months); most relapses occur within the first 6 months, but ~86% regain MMR and ~80% regain MR4 on restart; no progression to AP/BP. ENESTfreedom (frontline nilotinib): 51.6% in MMR or better at 48 weeks off therapy; 98.8% and 88.4% regained MMR and MR4.5 on reinitiation. ENESTop (imatinib then nilotinib): 57.9% in TFR at 48 weeks, 53.2% at 96 weeks; 92.9% regained MR4.0/MR4.5 on restart.
NCCN TKI discontinuation criteriaCriteria for TKI discontinuation (NCCN)
StepCriterion
EligibilityAge ≥18 years.
Chronic phase CML, no history of AP or BP.
On an approved TKI for at least 3 years.
Stable molecular response (MR4, BCR-ABL1 ≤0.01% IS) for ≥2 years (5 years is even better), documented on ≥4 tests ≥3 months apart.
Access to a reliable quantitative PCR with sensitivity ≥MR4.5 (≤0.0032% IS).
MonitoringMonthly for 6 months, then every 2 months through month 24 (ELN: through month 12), then every 12 weeks while in MMR.
RestartResume TKI within 4 weeks of loss of MMR (>0.1% IS), with monitoring every 4 weeks until MMR re-established, then every 3 months.
  • TKI withdrawal syndrome: musculoskeletal pain in ~25 to 40%, usually self-limited; NSAIDs.
  • A high Sokal score at diagnosis is a concerning finding but TKI withdrawal can still be considered.

TKI toxicity comparison

  • Class effects: all TKIs can cause myelosuppression, electrolyte disturbance, QT prolongation, and elevated LFTs.
TKI characteristic toxicities
TKICharacteristic toxicities
ImatinibFluid retention, periorbital edema, GI upset, rash, myalgias; hypophosphatemia and altered bone/mineral metabolism (bone-density effects variable, not a uniform decrease). Long-term follow-up: no significant late CV/pulmonary toxicity.
DasatinibPleural effusions (~20%), pulmonary HTN (rare but serious), QTc, GI bleed / platelet dysfunction.
NilotinibPAD, hyperglycemia, hypercholesterolemia; Black box QT prolongation (hold if QTc >480); elevated LFTs, amylase/lipase (pancreatitis), bilirubin; low magnesium. Nilotinib is dosed BID; asciminib is also BID in some regimens (40 mg BID option, 200 mg BID for T315I).
BosutinibDiarrhea (prominent, early), transaminitis; less long-term experience.
PonatinibBlack box arterial thrombosis (MI, CVA, PAD) and hepatotoxicity; VTE, pancreatitis, rash.
AsciminibThrombocytopenia, pancreatic enzyme elevation, hypertension, rare cardiovascular events (favorable overall profile).
  • TKI selection by comorbidity: pulmonary disease, CHF, or bleeding risk, avoid dasatinib; cardiovascular disease, diabetes, prolonged QTc, or pancreatitis, avoid nilotinib (and ponatinib for arterial disease). Older age favors imatinib.
  • Sequencing: start imatinib/nilotinib/dasatinib/bosutinib, then, for intolerance or a favorable actionable mutation, switch to another second-generation TKI; for true resistance (esp. after multiple lines) prefer ponatinib or asciminib, guided by kinase-domain mutation testing and adherence assessment; for second relapse or T315I, use ponatinib (or asciminib); allo-HSCT beyond that. Bosutinib in third line mainly for intolerance with a sensitive mutation profile.

Advanced Phase Disease

  • Accelerated phase: intensify TKI (2nd/3rd gen at higher dose, e.g. imatinib 600 mg, dasatinib 140 mg, nilotinib 400 mg BID, bosutinib 500 mg, ponatinib 45 mg); consider allo-HSCT if not in stable response.
  • Blast phase, myeloid: TKI + AML-type induction (e.g. 7+3 + TKI), then allo-HSCT in second CP.
  • Blast phase, lymphoid: TKI + ALL-type induction (hyper-CVAD or pediatric-inspired) +/- blinatumomab, then allo-HSCT.
  • TKI for BP: dasatinib or ponatinib (better CNS penetration; ponatinib for T315I or multi-TKI failure).
  • Goal: bridge to allo-HSCT, the only curative option for advanced CML.

Special Considerations

  • CML in pregnancy: avoid TKIs in the first trimester (teratogenic). Options: interferon-alfa (safe), leukapheresis. Selected patients may resume imatinib or nilotinib after ~16 weeks under specialist care; avoid dasatinib throughout pregnancy (fetal hydrops); later-pregnancy safety not established for bosutinib, ponatinib, or asciminib. Plan pregnancy after sustained deep molecular response (CMR/MR4).
  • Cardiovascular risk: nilotinib and ponatinib cause vascular events (PAOD, MI, CVA); screen ASCVD, control HTN, lipids, diabetes.
  • Pleural effusion (dasatinib): dose interruption + diuretic +/- steroid; switch TKI for recurrent effusions.
  • Pulmonary arterial hypertension (dasatinib): permanently discontinue dasatinib if PAH is confirmed (RHC/specialist evaluation); hemodynamics often improve after withdrawal but PAH persists in ~37%, sometimes needing PAH-directed therapy.
Veli Bakalov MD, Board Review Notes 2026
